紙箱包裝的制造尺寸為制箱時的下料尺寸，制造尺寸以膨脹箱坯上的壓線為基準。分切機上的壓痕輥在壓線位置壓出一條溝，壓線是這條溝的中間線，兩條壓線之間的距離是制造尺寸。將制造尺寸轉換為內部和外部尺寸是一種速成方法，但它們也有自己的測量方法。
The manufacturing dimension of carton packaging is the blanking dimension during carton making, and the manufacturing dimension is based on the pressing line on the expansion box blank. The indentation roller on the slitter presses out a groove at the line pressing position. The line pressing is the middle line of the groove, and the distance between the two lines is the manufacturing size. Converting manufacturing dimensions to internal and external dimensions is a quick fix, but they also have their own measurement methods.
在制造過程中，紙箱包裝可分為單拼接和雙拼接：?jiǎn)纹唇邮且豁?yè)成型箱，一般用于周長較小的產品；雙拼接也稱為兩頁箱。有些產品的周長太大，需要用兩個盒子拼接一個。然而，有時制造商會用兩片拼接一個不太大的紙箱，以利用生產過程中切割的剩余材料，有時用四片拼接。與一頁箱相比，兩頁箱有一個接頭，因此兩者的面積計算有一些細微的差異。
In the manufacturing process, carton packaging can be divided into single splicing and double splicing: single splicing is a one page shaped box, which is generally used for products with small perimeter; Double splicing is also called a two page box. The perimeter of some products is too large, and two boxes need to be used to splice one. However, sometimes the manufacturer will use two pieces to splice a small carton to make use of the remaining materials cut in the production process, and sometimes use four pieces to splice. Compared with one page box, two page boxes have a joint, so there are some slight differences in the area calculation between the two.
根據瓦楞層數和生產工藝水平確定產品接頭的制造尺寸，單瓦楞紙板35-40mm，雙瓦楞紙板45-50mm，三瓦楞紙板50mm。
The manufacturing size of the product joint is determined according to the number of corrugated layers and the production process level. The single corrugated board is 35-40mm, the double corrugated board is 45-50mm, and the three corrugated board is 50mm.
在計算紙箱包裝的展開面積時，需要考慮制造過程中回絲的損耗，回絲的尺寸需要根據紙板的層數來確定。一般來說是20-40毫米。在實際工作中，為了便于計算，我們采用了8加4的統一規則，即水平接頭和回絲的總和定為8厘米，縱向回絲的總和定為4厘米，即需要計算的總尺寸。
When calculating the unfolding area of carton packaging, the loss of return wire in the manufacturing process should be considered, and the size of return wire should be determined according to the number of layers of cardboard. Generally speaking, it is 20-40 mm. In practice, in order to facilitate the calculation, we adopted the unified rule of 8 plus 4, that is, the sum of the horizontal joint and the return wire is determined to be 8 cm, and the sum of the longitudinal return wire is determined to be 4 cm, that is, the total size to be calculated.
